| Model | 42VS007H115003016 | 42VS009H115003016 | ||
| Kragbron | 1 do, 220-240V, 50Hz | |||
| Verkoeling 1 | Kapasiteit | kW | 2.2 | 2.8 |
| kBtu/h | 7.5 | 9.6 | ||
| kragtoevoer | W | 40 | 45 | |
| Verhitting 2 | Kapasiteit | kW | 2.4 | 3.2 |
| kBtu/h | 8.2 | 10.9 | ||
| kragtoevoer | W | 40 | 45 | |
| lugvloei | m3/h | 530/504/478/456/439/418/400 | 569/540/515/485/462/443/421 | |
| Klankdrukvlak 3 | dB(A) | 36/35/34/33/31/30/29 | 36/35/34/33/31/30/29 | |
| klank krag vlak | dB(A) | 54/53/52/51/49/48/47 | 54/53/52/51/49/48/47 | |
| binnenshuise eenheid | Netto afmetings4 (BxHxD) | mm | 840×545×212 | |
| Verpakkingsafmetings (B×H×D) | mm | 939×639×305 | ||
| Netto/bruto gewig | kg | 21.4/25.6 | ||
| Pypverbindings | Vloeistof/gas pyp | mm | Ø6.35/Ø12.7 | |
| Dreineer pyp | mm | Ø16 | ||
| Model | 42VS012H115003016 | 42VS016H115003016 | ||
| Kragbron | 1 do, 220-240V, 50Hz | |||
| Verkoeling 1 | Kapasiteit | kW | 3.6 | 4.5 |
| kBtu/h | 12.3 | 15.4 | ||
| kragtoevoer | W | 55 | 60 | |
| Verhitting 2 | Kapasiteit | kW | 4.0 | 5.0 |
| kBtu/h | 13.6 | 17.1 | ||
| kragtoevoer | W | 55 | 60 | |
| lugvloei | m3/h | 624/591/557/522/473/420/375 | 660/625/583/542/501/475/440 | |
| Klankdrukvlak 3 | dB(A) | 37/36/35/34/32/31/30 | 37/36/35/34/32/31/30 | |
| klank krag vlak | dB(A) | 55/54/53/52/51/49/48 | 55/54/53/52/51/49/48 | |
| binnenshuise eenheid | Netto afmetings4 (BxHxD) | mm | 1040×545×212 | |
| Verpakkingsafmetings (B×H×D) | mm | 1139×639×305 | ||
| Netto/bruto gewig | kg | 26.1/30.6 | ||
| Pypverbindings | Vloeistof/gas pyp | mm | Ø6.35/Ø12.7 | |
| Dreineer pyp | mm | Ø16 | ||
| Model | 42VS020H115003016 | 42VS024H115003016 | 42VS028H115003016 | ||
| Kragbron | 1 do, 220-240V, 50Hz | ||||
| Verkoeling 1 | Kapasiteit | kW | 5.6 | 7.1 | 8.0 |
| kBtu/h | 19.1 | 24.2 | 27.3 | ||
| kragtoevoer | W | 88 | 110 | 130 | |
| Verhitting 2 | Kapasiteit | kW | 6.3 | 8.0 | 9,0 |
| kBtu/h | 21.5 | 27.3 | 30.7 | ||
| kragtoevoer | W | 88 | 110 | 130 | |
| lugvloei | m3/h | 1150/1094/1028/970/925/886/830 | 1380/1290/1205/1100/1033/955/870 | 1380/1290/1205/1100/1033/955/870 | |
| Klankdrukvlak 3 | dB(A) | 41/39/37/35/33/32/31 | 44/42/40/39/37/35/33 | 44/42/40/39/37/35/33 | |
| klank krag vlak | dB(A) | 59/57/55/53/51/50/49 | 62/60/58/57/55/53/51 | 62/60/58/57/55/53/51 | |
| binnenshuise eenheid | Netto afmetings4 (BxHxD) | mm | 1340×545×212 | ||
| Verpakkingsafmetings (B×H×D) | mm | 1425×639×345 | |||
| Netto/bruto gewig | kg | 31/39 | 32,7/40,7 | ||
| Pypverbindings | Vloeistof/gas pyp | mm | Ø9.53/Ø15.9 | ||
| Dreineer pyp | mm | Ø16 | |||
| Model | 42VS007H115002016 | 42VS009H115002016 | ||
| 42VS007H115001016 | ||||
| Kragbron | 1 do, 220-240V, 50Hz | |||
| Verkoeling 1 | Kapasiteit | kW | 2.2 | 2.8 |
| kBtu/h | 7.5 | 9.6 | ||
| kragtoevoer | W | 40 | 45 | |
| Verhitting 2 | Kapasiteit | kW | 2.4 | 3.2 |
| kBtu/h | 8.2 | 10.9 | ||
| kragtoevoer | W | 40 | 45 | |
| lugvloei | m3/h | 530/504/478/456/439/418/400 | 569/540/515/485/462/443/421 | |
| Klankdrukvlak 3 | dB(A) | 36/35/34/33/31/30/29 | 36/35/34/33/31/30/29 | |
| klank krag vlak | dB(A) | 54/53/52/51/49/48/47 | 54/53/52/51/49/48/47 | |
| binnenshuise eenheid | Netto afmetings4 (BxHxD) | MM (F4) | 1000 × 596 × 225 | |
| MM (F5) | 1000 × 677 × 220 | |||
| Verpakkingsafmetings (B×H×D) | MM (F4) | 1089 × 683 × 312 | ||
| MM (F5) | 1182 × 683 × 312 | |||
| Netto/bruto gewig | KG (F4) | 28.2/32.8 | ||
| KG (F5) | 28.2/35.8 | |||
| Pypverbindings | Vloeistof/gas pyp | mm | Ø6.35/Ø12.7 | |
| Dreineer pyp | mm | Ø16 | ||
| Model | 42VS012H115002016 | 42VS016H115002016 | ||
| 42VS012H115001016 | 42VS016H115001016 | |||
| Kragbron | 1 do, 220-240V, 50Hz | |||
| Verkoeling 1 | Kapasiteit | kW | 3.6 | 4.5 |
| kBtu/h | 12.3 | 15.4 | ||
| kragtoevoer | W | 55 | 60 | |
| Verhitting 2 | Kapasiteit | kW | 4.0 | 5.0 |
| kBtu/h | 13.6 | 17.1 | ||
| kragtoevoer | W | 55 | 60 | |
| lugvloei | m3/h | 624/591/557/522/473/420/375 | 660/625/583/542/501/475/440 | |
| Klankdrukvlak 3 | dB(A) | 37/36/35/34/32/31/30 | 37/36/35/34/32/31/30 | |
| klank krag vlak | dB(A) | 55/54/53/52/51/49/48 | 55/54/53/52/51/49/48 | |
| binnenshuise eenheid | Netto afmetings4 (BxHxD) | MM (F4) | 1200 × 596 × 225 | |
| MM (F5) | 1200 × 677 × 220 | |||
| Verpakkingsafmetings (B×H×D) | MM (F4) | 1289 × 683 × 312 | ||
| MM (F5) | 1382 × 683 × 312 | |||
| Netto/bruto gewig | KG (F4) | 33.1/38.2 | ||
| KG (F5) | 33.5/41.8 | |||
| Pypverbindings | Vloeistof/gas pyp | mm | Ø6.35/Ø12.7 | |
| Dreineer pyp | mm | Ø16 | ||
| Model | 42VS020H115002016 42VS020H115001016 | 42VS024H115002016 42VS024H115001016 | 42VS028H115002016 42VS028H115001016 | ||
| Kragbron | 1 do, 220-240V, 50Hz | ||||
| Verkoeling 1 | Kapasiteit | kW | 5.6 | 7.1 | 8.0 |
| kBtu/h | 19.1 | 24.2 | 27.3 | ||
| kragtoevoer | W | 88 | 110 | 130 | |
| Verhitting 2 | Kapasiteit | kW | 6.3 | 8.0 | 9,0 |
| kBtu/h | 21.5 | 27.3 | 30.7 | ||
| kragtoevoer | W | 88 | 110 | 130 | |
| lugvloei | m3/h | 1150/1094/1028/970/925/886/830 | 1380/1290/1205/1100/1033/955/870 | 1380/1290/1205/1100/1033/955/870 | |
| Klankdrukvlak 3 | dB(A) | 41/39/37/35/33/32/31 | 44/42/40/39/37/35/33 | 44/42/40/39/37/35/33 | |
| klank krag vlak | dB(A) | 59/57/55/53/51/50/49 | 62/60/58/57/55/53/51 | 62/60/58/57/55/53/51 | |
| binnenshuise eenheid | Netto afmetings4 (BxHxD) | MM (F4) | 1500 × 596 × 225 | ||
| MM (F5) | 1500 × 677 × 220 | ||||
| Verpakte afmetings (G × Y × D) | MM (F4) | 1589x683x312 | |||
| MM (F5) | 1682x683x312 | ||||
| Netto/bruto gewig | KG (F4) | 38.4/44.6 | 40.4/46.2 | ||
| KG (F5) | 39/47.7 | 40.7/49.4 | |||
| Pypverbindings | Vloeistof/gas pyp | mm | Ø9.53/Ø15.9 | ||
| Dreineer pyp | mm | Ø16 | |||
